Factory Customized Stainless Steel XTB15 Bushings

Product Description XTB15 Conveyor Pulley BushingThis XTB 15 sleeve has 1-1/4 Hole is a high-quality and durable liner. Some of the unique features of this liner are the 1045 grade steel structure and strict quality control to ensure that you always

Send Inquiry

Product Description

Product Description

XTB15 Conveyor Pulley BushingThis XTB 15 sleeve has 1-1/4 Hole is a high-quality and durable liner. Some of the unique features of this liner are the 1045 grade steel structure and strict quality control to ensure that you always receive high-quality and consistent products. We also provide matching product types manufactured to accept these types of liners. XTB15 liners are commonly used in various applications, including conveyors, cranes, and winches. They are a multifunctional and reliable sleeve that can be used multiple times Year.

XTB15 Bushings Specifications:

Bushing Part No.		XTB15 Bushings
Dimensions	L	1 1/8"
	U	3/8"
	H	2 7/8"
	S	5/32"
Cap Screws	No	4"
Cap Screws	Size	1/4" X 1"
Wt lbs		0.7

XTB15 Bushings Stock:

Bushing Part No.	Stock Bores	Keyseat	Key Supplied
XTB15 Bushing	5/8", 3/4", 7/8" 1", 1 1/8",1 13/16", 1 1/4", 1 7/16", 1 1/2"	3/16" X 3/32" 1/4" X 1/8" 3/8" X 1/8"	none none 3/8" x 5/16" x 1 1/8"

How To Install XTB15 bushings?

1. Preparation: Ensure that you have the necessary tools and equipment for the installation, including the appropriate size of XTB15 bushing, a torque wrench, and a suitable mounting surface.
2. Clean the Components: Thoroughly clean the shaft and the bore of the hub or component where the XTB15 bushing will be installed. Remove any dirt, debris, or old lubricants that could interfere with the installation or affect the performance of the bushing.
3. Lubrication: Apply a thin layer of lubricant to the inside surface of the XTB15 bushing as well as the shaft where the bushing will be mounted. This helps to reduce friction during installation and allows for easier removal in the future if necessary.
4. Positioning: Place the XTB15 bushing on the shaft, ensuring that it is aligned correctly with the hub or component. Make sure that the bushing is fully seated against any shoulders or stops on the shaft.
5. Tightening: Use a torque wrench to tighten the bushing's mounting screws or bolts in a cross-pattern sequence. Gradually tighten each screw or bolt to the specified torque value provided by the manufacturer. This ensures even pressure distribution and proper clamping force.
6. Verification: After the bushing is securely tightened, check that it is properly seated and aligned. Verify that there is no excessive axial or radial play between the shaft and the hub or component.

Please note that these instructions are general guidelines, and specific installation steps may vary depending on the design and specifications of the XTB15 bushing or any additional recommendations from the manufacturer. It is always recommended to refer to the manufacturer's instructions or consult with technical support for precise installation procedures to ensure accurate and successful installation of the XTB15 bushings.

Our company can provide our customers with the taper bush in the following table.

Factory Customized Stainless Steel XTB15 Bushings

Packaging & Shipping

Factory Customized Stainless Steel XTB15 Bushings

FAQ

Q: Are you trading company or manufacturer ?

A: Our group consists in 3 factories and 2 abroad sales corporations.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: How long is your delivery time ? What is your terms of payment ?

A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment.

Q: What is the exact MOQ or price for your product ?

A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation.

If you have another question, please feel free to contact us.
