Product Description

Forging Scraper Chain

high quality and low price
pls feel free to contact with us if you have any problem

No.	Type	Pitch	T(mm)	t(mm)	b(mm)	H(mm)	h(mm)	Hole(mm)
1	S16	100	30	15	16	27	8	Φ14
2	Z16	100	40	18	20	35	12	Φ17
3	S20	125	34	17	18	35	8	Φ17
4	Z20	125	50	24	26	46	15	Φ20
5	S30	142	46	22	23.5	49	14	Φ25
6	Z30	142	64	28.5	30.5	50	18	Φ25
7	142N	142	43	19	22	50	12.5	Φ25
8	150	150	38	18	19	40	10	Φ18
9	S25	160	48	23	25	39	13	Φ20
10	Z25	160	58	28	30	55	18	Φ18
11	3006	200	65	30	33	70	24	Φ32
12	MS55	200	80	35	38	70	25	Φ28
13	ML40	200	48	23	25	58	18	Φ25
14	MS32	200	42	20	22	50	12	Φ25
15	MG20	200	70	27	29	70	17	Φ35
