ARA series helical bevel gearbox straight bevel gearbox

90 Right Angle Bevel Gear Reducer

ARA series helical bevel gearbox straight bevel gearbox

hollow shaft bevel gearbox

aluminum bevel gearbox

• Ratio: 1:1,1.5:1 ,2:1 , 2.5:1 ,3:1 ,4:1 , 5:1
• Helical Gear Material: 20crmntih and 17crnimo6
• Shaft Material: 40cr Forged Steel
• Helical Gear Hardness: Hrc58-62
• Gear Housing: Cast Iron(Ht250 or Qt450)
• Weight: 2-488KG

• Product Features:

  1, chassis: high rigidity cast iron FC-25;

  2, gear: high-quality high-purity alloy quenched 50CrMnT processing by carburizing and grinding together;

  3, the spindle: high quality alloy steel 40Cr quenched high purity processing, with hanging load capacity.

  4, bearing: with a heavy load capacity tapered roller bearings;

  5, Seal: imported oil seal lips, with a high dust and anti-spill.



  Features:



  ARA series of spiral bevel gearboxes characteristics: small , full installation , light weight, aluminum alloy shell, shaft requires the use of corrosion-resistant steel when ordering . Lubricant has been added at the factory .



  ARA Series modular steering box using scientific design, features significant transmission equipment industry is an indispensable product . ARA series steering box excellent performance, light weight , small size, containing material ; rugged, high quality aluminum alloy die casting ; appearance, reasonable design, reverse operation , input and output using multi-dimensional structure, and the output diverse ways . For a wide range of torque, low noise , long life.

  Technical parameters:

  Power : 0.018KW ~ 4.94KW

  Torque : 6.95 ~ 46.8Nm

  Transmission ratio : 1:1, 2:1
