Product Description

worm gearboxes series QY reducer

Detailed Product Description

worm gearboxes series QY

speed reducer, speed reducers, worm reducers, worm reducer, worm gearbox, worm gearboxes

SIZE	RATIO	A	A₁	AB	AC	B	BB	BD	BE	BF	CC	H	NEMA Frame
133	5:1 10:1 15:1 20:1 30:1 40:1 50:1 60:1	2.12		3.96	4.00	6.03	4.00	2.88	2.00	3.25	1.333	4.66	56C
154		2.75		4.50	5.13	6.76	4.31	3.69	2.75	4.19	1.540	5.38	56C
175		2.75		4.37	4.81	6.75	4.31	3.38	2.75	4.19	1.750	5.75	56C
206		3.00		4.76	5.50	7.25	4.69	3.75	2.88	5.00	2.062	6.38	56C
237		3.56		5.10	6.13	7.78	5.08	4.06	2.88	5.00	2.375	6.94	56C 140TC
262		3.69		5.69	7.12	8.50	5.63	4.44	3.38	6.38	2.625	8.00	56C 140TC 180TC
300		4.50	5.93	5.67	8.50	10.25	6.75	5.50	4.00	7.00	3.000	8.88	56C 140TC
300		4.50	5.93	6.45	8.50	10.25	6.75	5.50	4.00	7.00	3.000	8.88	180TC
325		4.50	5.93	5.69	8.50	10.50	7.06	5.00	4.00	7.50	3.250	9.38	56C 140TC
325		4.50	5.93	6.47	8.50	10.50	7.06	5.00	4.00	7.50	3.250	9.38	180TC
375		5.75	7.42	6.01	9.50	11.88	7.75	6.38	4.75	8.50	3.750	10.44	56C 140TC
375		5.75	7.42	6.79	9.50	11.88	7.75	6.38	4.75	8.50	3.750	10.44	180TC 210TC
450		5.63	8.11	6.69	10.88	13.16	8.44	7.38	5.81	9.56	4.500	11.94	140TC
450		5.63	8.11	7.47	10.88	13.16	8.44	7.38	5.81	9.56	4.500	11.94	180TC 210TC
516		6.44	8.92	8.28	12.50	13.91	9.06	7.38	5.81	11.00	5.167	13.75	180TC 210TC
600		7.44	10.70	9.68	14.50	15.31	10.00	8.13	6.38	12.75	6.000	16.50	180TC 210TC

Raydafon Technology Group Co.,Limited is a group of factories, give customer one stop solution of power transmission and industrial products. We are in the position to supply wide range of products, including chains, sprockets, v-belt and v-belt pulleys, timing belt and timing belt pulleys, gears, speed reducers, motors, racks, couplings, and many other parts, like locking assembly, taper bushing, Chain guide, shaft collar, torque limiter, cam clutch, universal joint, motor base and motor slide, rod end, clevis, rubber mount, etc. We make special parts according to drawings and/or samples.
