OEM Custom Heavy-Duty Engineering Conveyor Chains (High-Grade)

Engineering Chain high quality and low price pls feel free to contact with us if you have any problem Overhead trolly conveyor makes full use of space and works together with ground facilities, widely used in furniture factory, bicycle plant, electro

Send Inquiry

Product Description

Engineering Chain

high quality and low price
pls feel free to contact with us if you have any problem

Overhead trolly conveyor makes full use of space and works together with ground facilities, widely used in furniture factory, bicycle plant, electronic products line, auto plants etc.

It can turn on both horizonal and vertical plans, run across long routes and automaticlly transmit objects along scheduled route to destination. Working efficiecy and quality is improved and management level will be strengthened.

Feature

1. Material: high-grade medium carbon steel

2. Perfectly used in poisonous and high-temperature environment

3. Automatical and safety

4. Smooth running

5. low noisy

6. easy operating

7. Customzied as your drawing and requirements

Specification

ITEM MODEL	Chain pitch (mm)	Min hanging distance (mm)	Single-span Weight(≤kg)	Chain's Allowed Pull Force(≤Ton)	Run speed (M/min)	Chain's Weight (kg/m)
UH-5075-S Standard Chain	75	150	30	3.5	0~12	4.2
UH-5075-HH 5 ton horizontal wheel heavy-type	75	150	35	3.5	0~12	4.58
CR5200HH horizontal wheel heavy-type	100	200	35	4	0~10	4.26
CR5200HV vertical wheel heavy-type	100	200	40	4	0~10	4.47
CR5200HA extra-heavy-duty	100	200	45	4	0~10	4.6
CR7200TA extra-heavy-duty type with hanger	100	200	50	5.5	0~10	5.35
CR7250TA extra-heavy-duty type with hanger	125	250	100	5.5	0~8	6
