Conveyor Chain

High-strength steel construction for durability
Precision-engineered links for smooth operation
Corrosion-resistant coating for extended lifespan
Multiple pitch options available (3", 4", 6")
Working load capacity up to 10,000 lbs
Operating temperature range: -20°F to 400°F
Available in standard and custom lengths

Model	Pitch (in)	Roller Diameter (in)	Tensile Strength (lbs)	Weight per Foot (lbs)
CC-300	3	2.5	8,500	4.2
CC-400	4	3.25	10,000	6.8
CC-600	6	4.5	15,000	9.5

FAQ 1: What maintenance does a Conveyor Chain require?

Conveyor Chains require regular lubrication every 200-300 operating hours using chain-specific lubricants. Inspect for worn links monthly and check tension every 3 months. Always clean debris accumulation and monitor for abnormal noises during operation which may indicate misalignment issues.

Feature	Benefit
Heat-treated pins	Increased wear resistance and longer service life
Sealed rollers	Protection from contaminants and reduced maintenance
Replaceable wear strips	Cost-effective refurbishment instead of full replacement

FAQ 2: How do I select the right Conveyor Chain for my application?

Consider these key factors: 1) Maximum load requirement including shock loads, 2) Operating speed (fpm), 3) Environmental conditions (temperature, moisture, chemicals), 4) Required service life, and 5) Compatibility with existing sprockets. Our CC-400 model suits most general industrial applications, while the CC-600 handles heavy-duty material handling.

Certified to ANSI/ASME B29.1 standards
ISO 9001:2015 quality management system
RoHS compliant materials
12-month manufacturer warranty
Technical support available 24/7

FAQ 3: What's the typical lifespan of a Conveyor Chain?

Under normal operating conditions with proper maintenance, our Conveyor Chains last 3-5 years in continuous operation (approximately 15,000-20,000 hours). Heavy-duty applications may require replacement every 2-3 years. Factors affecting lifespan include: load percentage of rated capacity, lubrication frequency, environmental conditions, and proper alignment/tensioning.
