XTB25 Bushings for Conveyor Pulleys

Product Description XTB25 bushing is a locking device used to connect the conveyor pulley to the drive shaft. These bushings are designed to provide a safe and reliable connection between the pulley and shaft, prevent slipping, and ensure smooth and

Send Inquiry

Product Description

China Manufacturer Factory Price XTB25 Bushings for Conveyor Pulleys

Product Description

XTB25 bushing is a locking device used to connect the conveyor pulley to the drive shaft. These bushings are designed to provide a safe and reliable connection between the pulley and shaft, prevent slipping, and ensure smooth and efficient power transmission. XTB25 casing is usually made of steel and adopts a conical design, making it easy to install at the end of the shaft. They are also equipped with integrated keyways that provide additional torque transmission capability and reduce the risk of shaft damage. One of the main advantages of XTB25 casing is its ease of installation. Unlike other types of locking devices such as keyless sleeves or shrink discs, XTB25 sleeves do not require any special tools or equipment to be installed. On the contrary, they can be easily installed onto the shaft using standard hex or torque wrenches. Overall, XTB25 bushings are a popular choice for conveyor pulleys and other applications that require safe and reliable shaft to pulley connections.

XTB25 Bushings Specifications:

China Manufacturer Factory Price XTB25 Bushings for Conveyor Pulleys

Bushing Part No.		XTB25 Bushings
Dimensions	L	1 7/8"
	U	5/8"
	H	4 7/16"
	S	1/4"
Cap Screws	No	4
Cap Screws	Size	3/8" X 1 3/4"
Wt lbs		2.6

XTB25 Bushings Stock:

Bushing Part No.	Stock Bores	Keyseat	Key Supplied
XTB25 Bushing	1", 1 3/16", 1 1/4" 1 7/16",1 1/2", 1 11/16", 1 3/4" 1 15/16", 2", 2 3/16" 2 7/16"	1/4" X 1/8" 3/8" X 3/16" 1/2" X 1/4" 5/8" X 1/4"	none none none 5/8" x 7/16" x 1 3/4"

Here are characteristics and features to consider when evaluating bushings:
1. Material: Bushings can be made from various materials such as steel, bronze, brass, or polymer composites. The choice of material depends on factors like load capacity, environmental conditions, and desired performance characteristics.
2. Load Capacity: Bushings are designed to withstand specific loads and forces. The load capacity of a bushing refers to the maximum load it can handle while maintaining proper performance and longevity.
3. Wear Resistance: Bushings should have good wear resistance to withstand friction and maintain their performance over time.This is especially important in applications with high-speed or high-load conditions.
4. Lubrication Requirements: Some bushings may require lubrication to reduce friction and wear. Others may be self-lubricating,incorporating materials or coatings that offer low friction and long-term lubrication properties.
5. Installation and Removal: Consider the ease of installation and removal of the bushings. Some bushings may have specific installation procedures or require specialized tools for proper mounting and disassembly.
6. Dimensional Specifications: Check the inner and outer diameter, length, and other dimensional specifications of the bushing to ensure compatibility with the shaft and housing or mounting structure.
It's important to consult the manufacturer or supplier of XTB25 bushings directly for accurate and comprehensive information about
their specific characteristics. They will be able to provide you with detailed product data, performance specifications, and any unique features associated with the XTB25 bushings.

Our company can provide our customers with the taper bush in the following table.

China Manufacturer Factory Price XTB25 Bushings for Conveyor Pulleys

Packaging & Shipping

China Manufacturer Factory Price XTB25 Bushings for Conveyor Pulleys

FAQ

Q: Are you trading company or manufacturer ?

A: Our group consists in 3 factories and 2 abroad sales corporations.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: How long is your delivery time ? What is your terms of payment ?

A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment.

Q: What is the exact MOQ or price for your product ?

A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation.

If you have another question, please feel free to contact us.
