2.It is manufactured according to ISO487 for farm equipment. Zinc-plated products and attachments are also available on request.
3.The main specification includes:S32,S42,S45,S52,S55,S55R,S62,S77,S88 etc
| Chain no. | Pitch | Roller Diameter |
Width Between Inner plate |
Pin Diameter |
Pin Length |
Plate Diamension |
Ultimate Tensile Strength |
Average Tensile Strength |
Weight Per Meter |
||
| p | D1 Max |
B1 min |
D2 Max |
L Max |
Lc Max |
H2 Max |
T Max |
Q Min |
q | ||
| mm | mm | Mm | Mm | mm | mm | Mm | mm | KN/LB | KN | Km/m | |
| S32 | 29.21 | 11.43 | 15.83 | 4.45 | 26.70 | 28.80 | 13.20 | 1.80 | 8.00/1818 | 21.60 | 0.86 |
| S42 | 34.93 | 14.27 | 19.05 | 7.01 | .34.30 | 37.00 | 19.80 | 2.80 | 26.70/6136 | 50.80 | 1.60 |
| S45 | 41.40 | 15.24 | 22.23 | 5.72 | .37.70 | 40.40 | 17.30 | 2.80 | 18.00/4091 | 36.10 | 1.66 |
| S52 | 38.10 | 15.24 | 22.23 | 5.72 | 37.70 | 40.40 | 17.30 | 2.80 | 18.00/4091 | 36.10 | 1.68 |
| S55 | 41.40 | 17.78 | 22.23 | 5.72 | 37.70 | 40.40 | 17.30 | 2.80 | 18.00/4091 | 36.10 | 1.80 |
| S55R | 41.40 | 17.78 | 22.23 | 8.90 | 41.00 | 44.00 | 22.40 | 3.50 | 45.00/10227 | 73.10 | 2.49 |
| S62 | 41.91 | 19.05 | 26.20 | 5.72 | 40.30 | 43.00 | 17.30 | 2.50 | 26.70/6067 | 36.10 | 1.87 |
| S77 | 58.34 | 18.26 | 22.23 | 8.92 | 43.20 | 46.40 | 26.20 | 4.00 | 45.00/10227 | 73.10 | 2.65 |
| S88 | 66.27 | 22.86 | 28.58 | 8.90 | 49.80 | 53.00 | 26.20 | 4.00 | 45.00/10227 | 73.10 | 3.25 |
We promise to offer you the right Agricultural Roller Chain with best price and best service! We have sufficient experience and high responsibility,welcome to send us your sample and we can provide with you what you want. We promise good price, best quality, fast delivery.We are sincerely looking for your cooperation!
