CA Type Size Steel Detachable Agricultural Conveyor Roller Chain Power Transmission Industrial Roller Chain

Product Description Product Name:CA type steel agricultural chain Agricultural chainQuick Details: Standard or Nonstandard Standard Place of Origin Zhejiang, China (Mainland) Brand Name EPT Model Number CA type color color Port: shanghai/ningbo Deliv

Send Inquiry

Product Description

Product Name:CA type steel agricultural chain Agricultural chain
Quick Details:

Standard or Nonstandard	Standard
Place of Origin	Zhejiang, China (Mainland)
Brand Name	EPT
Model Number	CA type
color	color
Port:	shanghai/ningbo
Delivery Time:	10/40days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	-

CA type steel agricultural chain Agricultural chain
The chains are made of premium steel alloy

CA type steel agricultural chain Agricultural chain

CA type steel agricultural chain is one of the .It is strictly built according to ISO487. These chains are typically applied in combine harvesters, round balers, feed wagon lifts, etc. Attachments are also available (A1, ATT, C5E, C6E, C11E, C13E, C17E, C30E, CPE, A19, F14,F4,K1,K19,K25,K27,).
The main specification includes:CA550,CA555,CA557,CA620,CA2050H,CA2063H

Chain no.	Pitch P mm	Roller Diameter D1 Max mm	Width Between Inner plates B1 Mm	Pin Diameter D2 Max Mm	Pin Length		Plate Diamension		Ultimate Tensile Strength Q MIN KN/LB	Average Tensile Strength KN	Weight Per Meter Km/m
Chain no.	Pitch P mm	Roller Diameter D1 Max mm	Width Between Inner plates B1 Mm	Pin Diameter D2 Max Mm	h L Max mm	h Lc Max mm	H2 Max Mm	H2 Max mm	Ultimate Tensile Strength Q MIN KN/LB	Average Tensile Strength KN	Weight Per Meter Km/m
CA550	41.40	16.87	19.81	7.19	35.0	38.0	19.3	2.80	39.10/8886	51.2	1.94
CA555	41.40	16.87	12.70	7.19	29.1	32.0	19.3	3.1	39.10/8886	56.0	1.72
CA557	41.40	17.78	20.24	8.00	37.4	40.6	23.1	3.10	55.61/12639	74.3	2.60
CA620	42.01	17.91	24.51	7.19	41.8	45.2	20.2	3.25	39.10/8886	55.1	2.35
CA2050H	38.10	11.91	12.70	5.94	29.2	31.6	18.00	3.25	31.10/6996	40.5	1.45
CA2063H	38.10	11.89	12.70	5.94	29.2	34.2	19.30	3.25	31.28/7109	40.5	1.65

All this kind Agricultural Roller Chain, we promise will offer the best price by the good quality in china!We can also produce according to your requirement.We promise that all our products are made of top quality materials.If you have any problems about details please contact us.
