PIN Lug COUPLING Pin Bush Couplings

The coupling consists of two hubs:one pin hub with the corresponding pins and a bush hub.The torque is transmitted via the steel pins with their taper elastomer rings and the corresponding bores in the bush hub. As a result all kinds of shaft misalig

Send Inquiry

Product Description

As a result all kinds of shaft misalignment,for example caused by inaccurate alignment of the driving or driven elements,is compensated for reliably and vibrations and shocks are compensated for excellently.

The coupling is maintenance-free and is used in general engineering and the pump industy,conveyor technology,etc.For an optimum adjustment to the different applications,14-off size are available covering torques up to 29100Nm.Apart from the standard programme customized solutions are available.

Features of Tl series pin & bush coupling

Torsinally flexible, matintenace free
Vibration-reducing
Tadial assembly/disassembly
Axial plug-in,failsafe
Good dynamical features
Short design
Ptotected surfaces
Elastomer made of NBR

Main Features
1. Applies to flexible drive shaft ,allowing a larger axial radial displacement and displacement.
2.Has a simple structure,easy maintenance .
3.Disassembly easy
4.low noise
5.Transmission efficiency loss,long useful working life
