WHT Series Hollow Flank Worm Reduction Gearbox

WHT series hollow flank worm reduction gearbox 1:Worm reducer 2:Ratio can be changed accoring your need 3:CE,ISO certifications 4:worm reduction gearbox. Worm Gearboxes Worm Gearboxes is mainly speed reducing for machineries in metallurgy,mining ,cra

Send Inquiry

Product Description

WHT series hollow flank worm reduction gearbox

1:Worm reducer

2:Ratio can be changed accoring your need

3:CE,ISO certifications

4:worm reduction gearbox.

Worm Gearboxes
Worm Gearboxes is mainly speed reducing for machineries in metallurgy,mining ,craning,
transportation,chemical and architectural industry.the worm shaft speed is no more than 1500
r/min. Ambient temperature-40°C-+40°C,when the ambient temperature is below 0°C,
before starting the lube must be heated up to above 0°C;when the ambient temperature is
above-40°C; you must be take cooled,The worm can rotate both CCW and CW.
Gear Box's Usage Field					Gear Box's Usage
1	Metallurgy				1	Agitator
2	Mine				2	Blast fan
3	Machine				3	Hoister
4	Energy				4	Compressor
5	Transportation				5	Petroleum industry
6	Water Conserbancy				6	Air Compressor
7	Tomacco				7	Crusher
8	Pharmacy				8	Plastic extruder
9	Printing Package				9	Conveyer
10	Chemical industry				10	Textile indutry
……					……
Power	0.12kw-160kw
Torque	50N.m-28000N.m
Ratio	5-63
Color	Chinese Red or as clients' requirement
Material	Nodular Cast Iron or as clients' requirement
Packing	Plywood Carton Box or as clients' requirement
	MODEL
1	CWU	CWS	CWO
2	SCWU	SCWS	SCWO
3	WHT	WHX	WHS	WHC
4	WD	WS
5	WPA	WPR	WPO
6	TPT	TPX	TPS	TPC
Mounting Methods	Foot Installment,flange,hollow shaft
