UDL Series Planetary Cone Disk Step-less Transmission Worm Gearbox Speed Variator with Motor

UDL Series planetary cone & disk step-less speed variator
high quality and low price
pls feel free to contact with us if you have any problem

Variator and speed motorvariator

For power ratings from 0,15 to 9,2 kW.
Silent, vibration-free running.
High efficiency.
Bidirectional rotation.
Control handwhel positional on either side.
Speed repeatability at max: ± 0,5%
Speed repeatability at min: ± 0,1%.
Regulaton sensibility: 0,5 rpm.
Casings (TX): diecast aluminium alloy.
Shafts: case hardened and tempered 20Cr steel after ground >HRC60

Internal components: 100Cr6 heat-treated steel.

All the sizes are painted with Ral 5010 blue epoxy-polyester powder.
